The Xencelabs Pen Display 16 Bundle is for creative professionals on the go. It’s designed with mobility in mind, and its light weight and slim profile make it easy to fit into most backpacks, allowing you to take it with you wherever you go. We have also included a carrying case. It's the ultimate blend of professionalism and portability.
Key Benefits:
1. 4K OLED Display with etched surface provides an edge-to-edge seamless, natural drawing experience.
2.Designed with portability in mind. Lightweight, slim profile allows for easy transport and connects to a laptop via a single USB-C cable
3.Pen pressure curve is responsive and adjustable to match drawing style
4.Two different pen sizes cater to different preferences – 3 Button Pen and Thin Pen
5.Exceptional glare reduction
6.Up to 1.07 billion colors and choice of four factory calibrated color spaces, including Adobe RGB, P3-D65, sRGB, REC 2020, REC 709
7.Enhance productivity. Includes Quick Keys with OLED display, physical dial, and up to 40 customizable shortcut keys per application
8.Intuitive driver includes the popular “Virtual Tablet” that enables pen control of other attached displays
9.Xencelabs Mobile Easel with two different drawing angles
10.Protective carrying case holds Pen Display 16, all included accessories and most laptops
11.Compatible with the Xencelabs Desktop Easel (sold separately)
Compatible Software:
PC: Windows® 7 or later (latest service pack/build)
Mac: OS X 10.12 or later (latest update)
Linux - Ubuntu 14.04 or above, Debian 9.5, CentOS 7.0 or above, RedHat 7.0 or above
USB-C port with DisplayPort Alternate Mode (UHD),
or DisplayPort (UHD) and USB-C/USB-A,
or HDMI 2.1 (UHD) and USB-C/USB-A
Internet access for driver download.
- Specifications
- Overview
Model number
LPH1612U-A
Color
Black
Warranty
2 years
Stand
Xencelabs Mobile Easel
Stand Adjustability
Two drawing angels, 18° and 32°
VESA Compliant
VESA compliant with Desktop Easel (sold separately)
Security
Kensington NanoSaver® Slot (Lock Port) - Lock not included
System Requirements
PC: Windows® 7 or later (latest service pack/build)
Mac: OS X 10.12 or later (latest update)
Linux - Ubuntu 14.04 or above, Debian 9.5, CentOS 7.0 or above, RedHat 7.0 or above
- Pen Display
Model number
LPH1612U-A
Product Weight
2.67 lbs (1.21 kg)
Product Dimensions
16.1 x 10.2 x 0.47 in (410 x 259.4 x 12mm)
Screen Size (measured diagonally)
15.6 in (39.6 cm)
Active Area
13.55 x 7.6 in (344.2 x 193.6 mm)
Display Resolution
3840 x 2160 pixels
Displayable Colors (maximum)
1.07 billion colors
Color Gamut Coverage Ratio (typ)
98% Adobe RGB (CIE1931)/ 98% P3-D65/ 99% sRGB/ REC 709/ REC 2020
Surface
Edge-to-edge tempered glass with Super-AG Etching™
Brightness
300 cd/m2, with power/ 170cd/m2 , one cable
Display Technology
Contrast Ratio
- Battery-free Pens
Pens
3 Button Pen + Eraser v2& Thin Pen + Eraser v2
Pen Technology
EMR
Pen Pressure Levels
8192 levels (Finely Tuned Pressure Curve)
Supported Pen Tilt Angle
60 degrees
Pen Resolution
5080 lpi
Pen Type
Pressure-sensitive, cordless, battery-free
Pen Switches
3 side switches (3 Button Pen v2)& 2 side switches (Thin Pen v2)
Replacement Nibs
10 Nibs v2(6 standard, 4 felt)
- Quick Keys
Model number
K02-A
Product Dimensions (W x H x D)
6.2 x 2.46 x 0.47 in / 157.6 x 62.5 x 12 mm
Product Weight
0.31 lbs / 142 g
Display
3.12-inch OLED display; shows key functions in landscape or portrait
Directions
4 directions (0° / 90° / 180° / 360°); text and symbols can be read horizontal or vertical on the OLED display
Security Slot
Kensington NanoSaver® Slot (Lock Port) - Lock not included
Hours per Charge
Up to 53 hours on 1.5 hour charge (charging times vary)
Custom Buttons
8 keys in 5 sets / 40 shortcuts per application
Dial
Up to 4 modes (user defined)
